Zetin Milling Machine ZTMM-A5

SKU:133148
Weight
63 Kg
Unit priceIn stock
AED 51.900,00
WhatsApp
Technical SupportDelivery & Setup

Product Description

Zetin Milling Machine ZTMM-A5

overview

Zetin Milling Machine ZTMM-A5 is a high-precision 5-axis dry milling machine designed for dental CAD/CAM applications. Featuring a high-speed 60,000 rpm spindle, ±0.005 mm milling accuracy, and support for multiple dental materials, it delivers reliable, efficient, and precise production for crowns, bridges, implant restorations, and other complex dental prosthetics.

Specifications

Size (L × W × H):
525 × 480 × 615 mm
Weight
63 Kg
Power:
1.2 kW
Number of Axes:
5
Processing Method:
Dry Milling
Milling Accuracy:
±0.005 mm
Compatible Material Size:
Ø98 × 10–25 mm
Spindle Speed:
Up to 60,000 rpm
Axis Rotation
A-Axis Rotation: -114° to +90° C-Axis Rotation: 360°
Tool Capacity
4 milling burs
Compatible Materials:
Zirconia (ZIR), PMMA, Wax, PEEK

Features

5-Axis Precision Milling

Advanced 5-axis motion enables accurate machining of complex dental restorations with no blind angles.

Ultra-High-Speed Spindle

60,000 rpm spindle delivers fast milling while maintaining excellent surface quality.

Exceptional Accuracy

Achieves milling precision of ±0.005 mm for highly accurate dental prosthetics.

Multi-Material Compatibility

Supports zirconia, PMMA, wax, and PEEK for a wide range of CAD/CAM applications.

Dry Milling Technology

Clean, maintenance-friendly dry processing eliminates coolant contamination.

Remote Maintenance Support

Built-in remote diagnostic capability simplifies troubleshooting and minimizes downtime.

Documents

Product catalog & brochure

Zetin Milling Machine ZTMM-A5

Explore the product information and technical details.

View / downloadOpens in a new tab
