UNIZ Ultrasonic U Wash

Type: CAD/CAM Machining Capabilities: Dry and Wet milling Axes: 5 continuous axes Monitor: 15.6-inch touchscreen Integrated Components: Built-in camera, Closed water circuit with filters Spindle Power: 3.2…

SKU:122214
Weight
220 Kg
Product enquiryIn stock
Price on request
Technical SupportDelivery & Setup

Product Description



The UNIZ Ultrasonic U Wash is an ultrasonic washing unit designed to thoroughly clean 3D printed appliances in as little as 6 minutes (2 wash cycles).
It uses an optimized 40,000 Hz standing‑wave chamber resonator and a powerful ultrasonic driver to deliver consistent washing performance.
With up to 2500 mW/cm² power density, it helps achieve tackiness‑free surfaces after washing.

A simple touch screen interface makes operation straightforward in daily workflows.
The cleaning chamber is designed for easy cleaning with zero moving parts inside the chamber.
UWash supports IPA saving by using different sets of cleaning cups and fixtures for different applications.
It also allows the cleaning chamber to be filled with water instead of IPA (as stated in the reference).

Specifications

Dimensions
60,2 x 85 x 88 cm
Weight
220 Kg
Cleaning Chamber Capacity
2 L
Ultrasonic Frequency
40,000 Hz
Ultrasonic Power
60 W
Power Density
Up to 2500 mW/cm²
Wash Time
1–10 mins
Operation Temperature
5–35°C
Cleaning Chamber Material
304 stainless steel
Cleaning Chamber Size
150 × 135 × 100 mm
Operation Interface
Touch screen
Power Voltage
AC 100–240 V, 50/60 Hz

Features

Tackiness‑Free in 6 Minutes

Achieves tackiness‑free surfaces in as little as 6 minutes using 2 wash cycles.

High Power Density

Provides up to 2500 mW/cm² power density for intensive ultrasonic washing.

40,000 Hz Ultrasonic Cleaning

Uses an optimized 40,000 Hz standing‑wave chamber resonator for thorough cleaning.

Powerful Ultrasonic Driver

Ultrasonic driver supports effective cleaning performance for 3D printed appliances.

Adjustable Wash Time

Set wash time from 1 to 10 minutes to match different applications.

Touch Screen Operation

Simple control via the built‑in touch screen interface.

Zero Moving Parts Chamber

Easy‑clean design with no moving parts in the cleaning chamber.

Water‑Fill Option

Cleaning chamber may be filled with water instead of IPA (per the reference).
