Lab Scanner digital dentistry

Lab Scanner Lodden DS130

Accuracy: ≤7µm Camera Resolution: 2 x 1.3MP Full Arch Scan Speed: 11s Impression Scan Speed: 27s Light Source: Blue Light Texture Scan: Yes

SKU:123017
Weight
9 Kg
Unit priceIn stock
AED 15.900,00
WhatsApp
Technical SupportDelivery & Setup

Product Description



Lodden Lab Scanner DS130 Overview

Lab Scanner Lodden DS130 is a smart and cost-effective choice for dental labs and clinics taking their first confident steps into the digital realm. Leveraging advanced blue light technology and a reliable accuracy of ≤7µm, this device perfectly covers all the essential needs for fabricating everyday restorations like crowns, bridges, and inlays/onlays. The impressive scan speed of the Lodden DS130—capturing a full arch in just 11 seconds—allows technicians to optimize their workflow and significantly boost lab productivity. It strikes an unparalleled balance between quality, speed, and affordability, paving the way for a smooth transition into the future of digital dentistry. For explore more click here.

Specifications

Model
DS130
Camera Resolution
2*1.3 MP
Light Source
Blue Light
Accuracy
≤7µm
Full Arch Scan Speed
11 seconds
Full Arch Impression Scan Speed
27 seconds
Scan Area
106(mm)*84(mm)*60(mm)
Texture Scanning
True Colour Scanning
True Colour Scanning
Output Formats
Output Formats
STL, PLY, OBJ
Dimensions (Size)
393(mm)*271(mm)*274(mm)
Weight
9 Kg
Connection
USB 3.0
Power Supply
DC 24VZ

Features

High Accuracy

Guarantees sufficient detail capture for common restorations with excellent marginal fit.

Dual Cameras

Reliably captures precise 3D data for routine design tasks.

"No Post-Processing" Ultra-Fast Scan Speed

The fastest full arch scan time in the DS series, maximizing throughput.

Completely Open System

Full compatibility with STL, PLY & OBJ formats for use in any CAD software.

Wide Application Range

Supports scanning of stone models, impressions, wax-ups, and articulators.

Compact & Lightweight

A small footprint and low weight (9kg) make it suitable for any lab or clinic workspace.

Plug-and-Play Simplicity

Easy setup and operation via a high-speed USB 3.0 interface.

Humanized Semi-Open Design

Offers easy access for model placement and removal, speeding up the workflow.

Documents

Product catalog & brochure

Lab Scanner Lodden DS130

Explore the product information and technical details.
