DAZZLE
L120 Basic 3D Printer
High-Precision Desktop 3D Printer
47µm XY Resolution
120x68x150mm Build Volume
Supports Windows & Mac
DAZZLE
Dazzle 3D Printer L120 Basic Overview
The Dazzle 3D Printer L120 Basic utilizes LCD (MSLA) technology to offer high-precision desktop 3D printing. It features a 2K LCD panel (2560*1440 Pixel) for pattern generation and a 48W, 405nm, Purple LED light source. The printer boasts an XY resolution of 47µm and a Z resolution of 10µm, with layer thicknesses ranging from 0.025mm, 0.035mm, 0.05mm, to 0.1mm.
Dazzle 3D Printer L120 Basic supports automatic and manual support generation and is compatible with Dazz 3D resins and third-party resins. Connectivity options include Wifi, Ethernet, and USB, with offline print capability. It has high-precision dual Z-Axis slides for stable operation. This model has a net weight of 6.5kg and an overall size of 221x175x403mm. Get more information here.
Technical Specifications
Model NO.
L120 Basic 3D Printer
Technology Type
LCD (MSLA)
Overall Size
221*175*403mm
Build Volume (X,Y,Z)
120*68*150mm
XY Resolution
47µm
Z Resolution
10µm
Layer Thickness
0.025mm, 0.035mm, 0.05mm, 0.1mm
Minimum Hole Diameter
0.3mm
Minimum Wall Thickness
0.2mm
Printing Speed
12-36mm/hr
Net Weight
6.5kg
Pattern Generation
2K LCD panel(2560*1440 Pixel)
Light Source
48W, 405nm, Purple LED
Resin Tank (Resin Vat)
FEP release film, aluminium alloy frame
Supports
Automatic and manual supports generation
Input File
STL./OBJ./SLC./DDEB./DDWP
Connectivity
Wifi/Ethernet/USB
Offline Print Capability
Yes
Z-Axis Slide
High-precision dual Z-Axis slides
Resins
Dazz 3D resins, 3rd party resins compatible
Software
DDStarter
Systems Requirement
Windows, Mac
Touch Screen
No
Power
Input: 100-240V 50-60Hz 2.5A, Output: 24V DC 4A
Resin Fill System
NO
Air-purification System
NO
Sliding Peel Process with Wipe
NO
Key Features of the L120 Basic
LCD (MSLA) Technology
Utilizes LCD (MSLA) for detailed printing.
High Resolution
Features 47µm XY Resolution and 10µm Z Resolution for precise prints.
Versatile Layer Thickness
Supports various layer thicknesses from 0.025mm to 0.1mm.
Broad Connectivity
Offers Wifi, Ethernet, and USB connectivity.
Dual Z-Axis Slides
Equipped with high-precision dual Z-Axis slides for stability.
